Model Overview

Our pure electric logistics vehicle is newly modified from a pure electric bus body, equipped with a self-developed vehicle control system and matched with a self-developed permanent magnet synchronous motor. The vehicle has a cargo volume of 13.6m³, exce

Tech Performance

Model
SYC5040XXYBEVT1

SYC5040XXYBEVT1

Total Models 1

Product Specifications

Exterior Dimensions (L*W*H) 5995×1995×2650
Wheelbase (mm) 3665
Rated Capacity (Persons) 2
Curb Weight / Gross Vehicle Weight (kg) 2865/4490

Power Battery

Battery Type CATL, Lithium Iron Phosphate
Battery Capacity (kWh) 79

Drive System

Motor Model TZ405XSD31
Motor Type Permanent Magnet Synchronous Motor, Water-cooled
Controller KTZ38X40SP25-S1.0 / KTZ38X40SP25

Body Configuration

Motor Rated Power/Torque (kW/r/min/N·m) 70/390/780
Motor Peak Power (kW/r/min/N·m) 140
Other Features

Standard split-type headlights with automatic high/low beam and height adjustment;

Equipped with a 13.6 m³ super-large cargo box, far exceeding similar models;

The vehicle adopts a pyramid-structured fully loaded body for better force distribution.
